Landsat 8 Assayii Lake Fire Imagery

These images were acquired from Landsat 8 imagery flown pre-burn on June 7, 2014 and during the fire on June 23, 2014. Each image contains a slider to compare two images. If viewing the images on your desktop, hover your mouse over the image and a green slider will appear over the image. If using a mobile device, tap on the left or right side of the image.

Natural Color - Bands 4,3,2

Notice that the fire is hard to detect in this natural color image.

before
after

Shortwave Infrared False Color - Bands 7,5,4

Notice how much easier the fire is to detect using this false color shortwave infrared image. The dark, magenta blob is the current Assayii Lake Fire.

before
after

Thermal Infrared - Bands 10,5,2

Again, notice how much easier the fire is to detect in this false color thermal infrared image. The brighter the color, the hotter the temperature of the surface.

before
after
